T623-E3.5 (185026-1,185027-1)

Short Description

Part No.	T623-E3.5A	T623-E3.5B
Material	QSn	QSn
Thickness (mm)	0.3	0.3
Wire Range (mm²)	0.5~1.0	1.0~2.0
Package Qty	2500 PCS/ROLL	2500 PCS/ROLL
Basic Spec	L: 19.4 W: 3.0 H: 4.0	L: 19.4 W: 3.0 H: 4.0
Notes	185026-1 Waterproof type	185027-1 Waterproof type

Send email to us

Description

This splice terminal achieves 50N tensile strength with FLRY-A/B wires, utilizing a dual-crimp design (conductor+insulation) for 0.5-2.5mm² cables. The E-shaped contact spring maintains <15mΩ resistance after 25 insertion cycles, compliant with ISO 8092-3 standards for underhood wiring modifications and aftermarket harness extensions.

Product Parameters

Attribute	Value
Brand	TE Connectivity
Type	Tab Terminal
Gender	Female
Contact Plating	Tin
Current Rating	10A
Mounting Type	Wire
Termination Method	Crimp
Maximum Operating Temperature	+130°C
Width	1.6mm
Minimum Operating Temperature	-40°C

Compatible Parts

27.06.2025In3.5 Series 标签：Automotive Connectors, Customized Housings Socket

Customized DJ80211-3.5-21 (240PC02S8001) 2 Pin female auto connector Housing

Application Sectors

Automobile manufacturing

Industrial equipment

Intelligent robots

New energy field

Applications in automotive manufacturing, industrial equipment, new energy fields, power systems, aerospace, robotics, smart homes, power systems, communication infrastructure, etc.
