45-degree angled compression lug made from T2 copper with two mounting holes, 3/8" stud connection, 1-inch hole spacing, and black insulation coding.45-degree angled compression lug made from T2 copper with two mounting holes, 3/8″ stud connection, 1-inch hole spacing, and black insulation coding.
45-degree angled compression lug made from T2 copper with two mounting holes, 3/8" stud connection, 1-inch hole spacing, and black insulation coding.
45-degree angled compression lug made from T2 copper with two mounting holes, 3/8" stud connection, 1-inch hole spacing, and black insulation coding.

45° T2 Copper Compression Lug | 2-Hole Mounting | 3/8″ Stud | 1″ Spacing | Black Code | Standard Barrel

Description

  • Feature : Precision-engineered 45-degree lug manufactured from high-conductivity T2 copper, featuring dual-hole mounting with 1-inch center spacing, 3/8″ stud connection, and black insulation

  • Advantage : Provides enhanced mechanical stability through two-point mounting while maintaining optimal electrical conductivity and corrosion resistance in angled applications

  • Benefit : Ensures vibration-resistant connections in high-stress environments, reduces maintenance costs, and delivers reliable long-term performance in industrial power systems

Data Overview

  • Material: T2 Copper (High Conductivity)

  • Mounting: 2-Hole Pattern

  • Hole Spacing: 1 Inch

  • Stud Size: 3/8″

  • Tongue Angle: 45°

  • Barrel Type: Standard

  • Color Code: Black

  • Standards: UL 486A, RoHS Compliant

  • Temperature Range: -40°C to 125°C

Application Scenarios
Industrial power distribution, heavy equipment wiring, renewable energy systems, electrical substations, and applications requiring secure, vibration-resistant angled connections.

Send email to us

Dimensions

Bolt Size3/8 in
Hole Spacing(H)1.00 in
Tang Width (C)0.83 in
Barrel length (B)0.94 in
Overall length (L)2.83 in
Inner diameter (ID)0.45 in
Outer diameter (OD)0.56 in

General Specifications

ColourBlack
MaterialCopper
Tongue TypeStandard
Tongue Angle45 degree
SurfaceTin-plated
Inspection WindowWith inspection window

Dimensions

Electrical Specifications
Rating – Maximum Voltage35KV
Environmental Specifications
Operating Temperature-40 °C to +90°C (-40 °F to +212 °F)
Storage Temperature-40 °C to +80 °C (-40 °F to +176 °F)
Packaging and Weights
IncludedLug
Packaging Quantity and UOM1 pcs
Certifications
ISO 9001:2015Designed, manufactured and/or distributed under this quality management system
