L6-08H/W Compression lugs 6AWG 1 Hole 45° Tongue #8 Stud code Blue Wire termination & connectors

L6-08H/W 45° Angled Compression Lug | 6 AWG | #8 Stud | Single Hole | Code Blue

Description

The ‌1-14W‌ grounding lugs feature ‌T2 pure copper construction‌ (99.9% conductivity) with industry-leading corrosion protection options:

‌Standard green polymer coating‌ (safety color-coding)
‌Premium plating options‌:
- Hot-dip galvanized (ASTM B633 Type II)
- Electroless nickel (5-10μm thickness)
‌Precision 1/4″ (6.35mm) mounting hole‌
‌Cold-forged terminal‌ (meets UL486A/B)
‌-60°C to +200°C operational range‌
‌Stamped AWG1/42.4mm² markings‌

‌Applications:‌ Critical for substation grounding, solar farms, and petrochemical facilities. Compliant with IEEE 80, NEMA, and IEC 62561 standards.

Send email to us

Dimensions

Bolt Size	#8 in
Tang Width (C)	1.12 in
Barrel length (B)	1.06 in
Overall length (L)	1.53 in
Inner diameter (ID)	0.22 in
Outer diameter (OD)	0.31 in

General Specifications

Colour	Blue
Material	Copper
Tongue Type	Standard
Tongue Angle	45 degree
Surface	Tin-plated
Inspection Window	With inspection window

Dimensions

Electrical Specifications
Rating – Maximum Voltage	35KV
Environmental Specifications
Operating Temperature	-40 °C to +90°C (-40 °F to +212 °F)
Storage Temperature	-40 °C to +80 °C (-40 °F to +176 °F)
Packaging and Weights
Included	Lug
Packaging Quantity and UOM	1 pcs
Certifications
ISO 9001:2015	Designed, manufactured and/or distributed under this quality management system
