LYF45-25/10 LYF 45 Degree 4AWG 25m㎡ Bend Copper Tube Terminal Cable lugs

Description

Military-Grade T2 Copper‌: The ultra-pure T2 copper core (99.95% conductivity) ensures minimal voltage drop in high-current applications like data center power distribution.

Precision 45° Miter Cut‌: The laser-cut 45-degree angle provides clean terminations in tight spaces, accommodating 25mm² cables with 15% better bend radius than standard 90° designs.

Dual-Surface Treatment‌: Features micro-roughened inner barrel for superior crimp retention and mirror-polished outer surface for corrosion resistance.

Compact Space Solutions‌: Perfect for server rack wiring, automation control cabinets, and EV battery assemblies where oblique terminations are required.

Global Compliance‌: Certified to UL 486E-2025 and EN 13600 standards, with optional lead-free tin plating for RoHS-compliant installations.

Dimensions

φE(mm)10.5
ΦD(mm)11
Φd(mm)8
W(mm)17
B(mm)24
C(mm)25

General Specifications

MaterialPure Copper
Copper Content≥99.9%
SurfaceTin-Plated
Tongue Angle45 Degree
Inspection WindowWith inspection window

Dimensions

Electrical Specifications
Rating – Maximum Voltage35KV
Environmental Specifications
Operating Temperature-40 °C to +90°C (-40 °F to +212 °F)
Storage Temperature-40 °C to +80 °C (-40 °F to +176 °F)
Packaging and Weights
IncludedLug
Packaging Quantity and UOM1 pcs
Certifications
ISO 9001:2015Designed, manufactured and/or distributed under this quality management system
