TT16-6 tulip copper cable lug 6AWG 16m㎡ (Bellmouth) TT Copper Cable Lug

Description

  • ‌T2 Copper Excellence‌: Forged from 99.9% pure T2 copper (IACS ≥98%) for superior current flow and oxidation resistance, exceeding ASTM B187 standards.
  • ‌Bellmouth Innovation‌: Flared entry design enables effortless wire insertion, reducing installation time by 30% compared to standard lugs.
  • ‌Precision Compatibility‌: Engineered for 6AWG (16mm²) cables with 5/16″ stud hole, ideal for solar panels, marine wiring, and heavy-duty machinery.
  • ‌Certified Reliability‌: UL 486A & RoHS compliant, operating temperature range -50°C to 120°C.
Send email to us

Dimensions

φE(mm)6.4
ΦD(mm)7.8
Φd(mm)5.6
W(mm)11.9
B(mm)17
L(mm)33

General Specifications

MaterialPure Copper
Copper Content≥99.9%
SurfaceTin-Plated
Tongue AngleStraight
SurfaceTin-plated
Inspection WindowWith inspection window

Dimensions

Electrical Specifications
Rating – Maximum Voltage35KV
Environmental Specifications
Operating Temperature-40 °C to +90°C (-40 °F to +212 °F)
Storage Temperature-40 °C to +80 °C (-40 °F to +176 °F)
Packaging and Weights
IncludedLug
Packaging Quantity and UOM1 pcs
Certifications
ISO 9001:2015Designed, manufactured and/or distributed under this quality management system
