TU16-4 Bellmouth Copper Tube Terminal AWG6# 16m㎡ Cable Lug

Description

‌Premium T2 Copper Construction‌: The TU16-4 terminal features high-purity T2 copper, ensuring superior electrical conductivity and corrosion resistance for long-lasting performance.

‌Precision Bellmouth Design‌: Engineered for AWG 6# (16mm²) cables, this terminal provides a secure, low-resistance connection with its smooth bellmouth entry, reducing cable stress.

‌Versatile Applications‌: Ideal for industrial, automotive, and power distribution systems, this cold-pressed terminal delivers consistent performance under extreme conditions.

‌Certified Quality‌: Compliant with industry standards for power transmission efficiency, making it a trusted choice for professional electrical installations.

Send email to us

Dimensions

φE(mm)	4.3
ΦD(mm)	8
Φd(mm)	5.6
W(mm)	11
B(mm)	11
L(mm)	29.5

General Specifications

Material	Pure Copper
Copper Content	≥99.9%
Surface	Tin-Plated
Tongue Angle	Straight
Inspection Window	With inspection window

Dimensions

Electrical Specifications
Rating – Maximum Voltage	35KV
Environmental Specifications
Operating Temperature	-40 °C to +90°C (-40 °F to +212 °F)
Storage Temperature	-40 °C to +80 °C (-40 °F to +176 °F)
Packaging and Weights
Included	Lug
Packaging Quantity and UOM	1 pcs
Certifications
ISO 9001:2015	Designed, manufactured and/or distributed under this quality management system
