AD80-10 AD Copper Tube Terminals AWG3/0# 76.3-96.3m㎡ Cold-Pressed Terminal

Description

The AD80-10 cold-pressed copper tube terminals are designed for high-current applications, featuring T2 pure copper construction for superior conductivity and durability.

Compatible with AWG 3/0 (76.3-96.3mm²) wires, these terminals provide reliable performance in industrial, automotive, and electrical systems.

The cold-pressed design ensures a strong mechanical connection, while the T2 copper material offers excellent corrosion resistance and long-term stability. Ideal for demanding environments where power transmission efficiency is critical.

Send email to us

Dimensions

φE(mm)	11
ΦD(mm)	17.9
Φd(mm)	14.9
W(mm)	26.7
B(mm)	19
L(mm)	82.3
H(mm)	25.4

General Specifications

Material	Pure Copper
Copper Content	≥99.9%
Surface	Tin-Plated
Tongue Angle	Straight
Inspection Window	With inspection window

Dimensions

Electrical Specifications
Rating – Maximum Voltage	35KV
Environmental Specifications
Operating Temperature	-40 °C to +90°C (-40 °F to +212 °F)
Storage Temperature	-40 °C to +80 °C (-40 °F to +176 °F)
Packaging and Weights
Included	Lug
Packaging Quantity and UOM	1 pcs
Certifications
ISO 9001:2015	Designed, manufactured and/or distributed under this quality management system
